​Description :

1. 100% brand new and high quality
2. The meter does not require series circuit to measure, no external shunts.
3. We can measure the circuit voltage and current through transformer.
4. Waterproof housing, dual color display, can display real-time power and voltage
5. With voltage calibration potentiometer, if error, you can calibrate yourself, comes "zero" potentiometer on the transformer.
6. Can be measured forward and reverse current of the line, forward display "positive" current (ammeter decimal lit or not lit), the reverse display negative "current (ammeter decimal slow flash)
7. High reliability, high resistance to current shocks, it will not be easy to damage ammeter
8. Usable range: Access solar systems, cars, storage battery car and motorcycles battery line, for monitoring the battery voltage, handle the battery, discharge status, it also can be used for other products voltage and current measurements

Specifications:

• Display: 0.28 "LED, two colors (red and blue)
• Size: L54 * W30 * H21mm
• Threading gat-Diafragma: 8.5mm
• Transformator Size: L23.3 * W23 * T9.3mm
• Measurement rate: 500 mS / time
• Accuracy: 1% (2 words)
• Lead Length: about 150mm
• Humidity: 10 ~ 80% (non-condensing)
• Working pressure: 80 ~ 106kPa
• Sunlight: no direct exposure
• Operating voltage: DC 4.5 to 30V
• Measure voltage: DC 0 to 100V
• Minimum resolution(V): 0.1V
• Minimum resolution(A): 0.1A
• Operating current: <20mA

Voltage Display - voltage meter 10A

RM6.99

Specification :
Measure current:10A (require external shunt)

Voltage Display - voltage meter 50A

RM14.99

Specification :
Measure current:50A (require external shunt)



Voltage Display - voltage meter 100A

RM19.99

Specification :
Measure current:100A (require external shunt)
